Enclosures. Cable Management Wire - AWG - PTFE (Lightweight Wall) - Polytetrafluoroethylene Outer Jacket - 4 ft and coils

HS2TFL30

Enclosures. Cable Management Wire -  AWG - PTFE (Lightweight Wall) - Polytetrafluoroethylene Outer Jacket - 4 ft and coils

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

This picture is representative only and may not match the specific configuration of the product listed on this page. Please refer to the product specifications for more information on this part number and its exact configuration.


OR

Quick Overview

30 AWG PTFE 2:1 Heat Shrink Tubing (30,28, 26 AWG are not covered under AMS-DTL-23053/12).
30 AWG PTFE 2:1 Lightweight Wall Heat Shrink Tubing

Specifications

SKU HS2TFL30
Manufacturer IWC Approved
Type Enclosures
Shrink Temperature 662°F / 350°C
Continuous Use Temp -100° to 500°F / -75° to 260°C
Weight 0.0000
Insulation Material PTFE (Lightweight Wall) - Polytetrafluoroethylene
Amount 4 ft and coils
Color Natural - Translucent to Opaque White
Min. Expanded ID (in) .034
Recovered Wall Thickness (in) .006 ± .002
Max Recovered ID (in) .015
AWG Size 30
