Enclosures. Cable Management Wire - AWG - PTFE (Thin Wall) - Polytetrafluoroethylene Outer Jacket - 4 ft and coils

HS2TFT00

Enclosures. Cable Management Wire -  AWG - PTFE (Thin Wall) - Polytetrafluoroethylene Outer Jacket - 4 ft and coils

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

This picture is representative only and may not match the specific configuration of the product listed on this page. Please refer to the product specifications for more information on this part number and its exact configuration.


OR

Quick Overview

0 AWG PTFE 2:1 Heat Shrink Tubing
0 AWG PTFE 2:1 Thin Wall Heat Shrink Tubing

Specifications

SKU HS2TFT00
Manufacturer IWC Approved
Type Enclosures
Military Specification AMS-DTL-23053/12 Class 3
Shrink Temperature 662°F / 350°C
Continuous Use Temp -100° to 500°F / -75° to 260°C
Weight 0.0000
Insulation Material PTFE (Thin Wall) - Polytetrafluoroethylene
Amount 4 ft and coils
Color Natural - Translucent to Opaque White
Min. Expanded ID (in) .470
Recovered Wall Thickness (in) .015 ± .004
Max Recovered ID (in) .347
AWG Size 0
